OPTICS

13-element 10:1 zoom high-resolution optic system

Beam aperture: 6.0° to 60°

Fast motorised linear zoom

Tempered anti-reflective coated lenses

178 mm frontal lens for greater performance

LIGHT SOURCE

Domino-S

75,000-lumen 8000 K white light engine

Total luminaire output: up to 51,000 lumens

Colour temperature output: 7000 K

CRI: greater than 70

Domino-TC

56,000-lumen 7000 K white light engine

Total luminaire output: up to 36,400 lumens

Colour temperature output: 6500 K

CRI: greater than 90

Domino-S & Domino-TC

Rated life (L70): up to 40,000 hours

Flicker-free source management suitable for TV applications and all video-recorded events

MOVEMENT

Extremely accurate positioning

Moving-head operated via either 8- or 16-bit resolution

High-resolution stepper motors operated via microprocessors to ensure extreme accuracy and smooth movement

Pan and tilt automatic repositioning

Moving-head range: 540° (pan), 270° (tilt)

COLOURS

Sophisticated colour mix system providing CMY colour mixing

Variable CTO colour temperature correction

Fixed colour wheel with six complementary colours

2 CRI and TM30 optimizer filters

GOBOS

2 indexable rotating gobo wheels with 7 high-precision glass gobos, plus open position

Adjustable-speed rotating gobo in both directions

Gobo diameter: 30.0 mm

Image diameter: 25.0 mm

Gobo thickness: 1.1 mm

FRAMING SYSTEM

4 individually positionable shutter blades on a 100% surface area in all positions

Rotation of the framing system module: +/- 60°

IRIS DIAPHRAGM

Fast iris diaphragm with adjustable dynamic effects

Iris range: 15% to 100% open

FROST

2 frost filters: one light, one heavy

EFFECTS

Focusable black & white graphic animation effect-wheel with continuous rotation in both directions

Focusable colour graphic animation effect-wheel with continuous rotation in both directions

2 rotating and indexable prisms: one 5-facet circular, one 4-facet linear

DIMMER / STROBE

Electronic dimmer, allowing perfect light adjustment from 0 to 100% without colour variation

Strobe effect, with speed adjustment from 1 to 25 flashes per second

SOFTWARE FEATURES

Local DMX addressing of luminaire and optional parameters through its built-in LCD control panel

Remote DMX addressing of luminaire and optional parameters through a standard RDM DMX controller

Information menu including hour counter, temperature, software version

HARDWARE FEATURES

Graphic LCD display for addressing and special function settings, with flip function

5 menu buttons to set the functions

Excess temperature protection

Integrated wireless CRMX TiMo™ RDM receiver from LumenRadio™

Domino-IP65

IP65 XLR 5-pin male and female connectors for DMX connection

IP65 RJ45 IN / OUT connectors for ArtNet™ connection

IP65 powerCON TRUE1 male connector for power connection

Domino-IP66

DMX IN / OUT tails to bare end for IP66 DMX connection

Ethernet IN / OUT tails to bare end for IP66 ArtNet™ connection

Power tail to bare end for IP66 power connection

CONTROL

DMX 512 protocol, through DMX cable or a wireless system

DMX-RDM compatible

Stand-alone mode and Master/Slave modes

ArtNet™ & sACN protocol through Ethernet cable

Local control panel, with IP65 LCD display

Choice of 3 DMX modes (from 44 to 66 DMX channels)

POWER SUPPLY

Electronic supply with active PFC

110 to 240 Volts – 50/60Hz

Power: 1700 W maximum

COOLING SYSTEM

Advanced liquid cooling system

IP68 self-adjusting variable speed fans for quiet operation (Auto mode)

Selectable ventilation user modes with a new Silent Mode

Safety protection against temperatures excesses

HOUSING

Moving-head skeleton made of die-cast aluminium

Base in die-cast aluminium

Heatsinks in aluminium and copper

Moulded covers in in die-cast aluminium

Two-side handles for transportation

Four heavy-duty feet for better stability

IP65 protection rating

Exterior finish: black (Carbon)

INSTALLATION

Fastening brackets system: two Omega ¼ turn brackets designed for use with standard clamps

Mounting points: eight ¼ turn locking fittings allowing installation of Omega brackets on luminaire

Safety cable attachment point

OPERATING PARAMETERS

Operating positions: all (device on floor or fixed to a support)

Maximum permitted ambient temperature (Ta max): 45° C (113° F)

Minimum permitted ambient temperature (Ta min): -20° C (-4° F)

Minimum usage distance: 3.0 m (9.84 ft)

COMPLIANCE

EU (EMC&LVD)

EMC Directive 2014/30/EU

LVD Directive 2014/35/EU

US (Safety & EMC)

UL 1573

FCC Part 15, Subpart B: 2018

SIZE

Product: 490 x 841 x 330 mm (l x h x d)

Flight-case foam: 715 x 665 x 555 mm (l x h x d)

WEIGHT

Product: 52 kg

PRODUCT CODES

012640: DOMINO-S – CLASSICAL IP65 9 SERIES

012642: DOMINO-S – CLASSICAL IP66 9 SERIES

012650: DOMINO-TC – CLASSICAL IP65 9 SERIES

012652: DOMINO-TC – CLASSICAL IP66 9 SERIES
