POWER SUPPLIES

AC power input Neutrik PowerCON True1 (IP65) 100-240V, 50/60 Hz

INPUT POWER

540 VA @230Vac - 50Hz

LIGHT SOURCE

330W X8 HRI Sirius Osram arc lamp

OPTICS

Zoom 3°- 36°, Linear and motorized

COLOR SYSTEM

CMY colour mixing

15 colours on 3 wheels

2 CTO filters

EFFECTS SECTION

Rotating Gobo Wheel: 8 interchangeable glass gobos

Static Gobo Wheel: 18 static gobos

Six beam reducers (down to 0.5°)

Rotating 4-facet prism on dedicated channel

Rotating 8-facet prism on dedicated channel

Dynamic Animation Wheel

Linear soft edge frost filter

Dimmer and stop/strobe

Dense, Sharp, Parallel Light Beams

Extremely quick movements

Excellent visual effect projections

Wide and sharp aerial effects

CONTROL AND PROGRAMMING

Control signal USITT DMX 512

31 DMX 512 control channels

Protocols RDM, WebServer and Art-Net

Display Graphic LCD backlit b/w Display

Display battery Long life self-charging buffer battery

Pan/Tilt Resolution 16 bit

Focus Resolution 16 bit

Gobo Resolution 16 bit

Dimmer Resolution 16 bit

DMX signal connection 5 pole XLR input and output

Ethernet Input

Firmware update Software upload through Ethernet input

BODY

Aluminum and steel structure with plastic covers
